Part Canopy
All Rounder Trailer
The best of both worlds — a secure, weatherproof canopy plus external tray space. Ideal for gas bottles, fire extinguishers and other items you want kept out of the service body. Choose your preferred canopy and tray length for a perfect match.
FEATURES & BENEFITS
Aluminium polymer co-bonded construction.
For the lightest possible weight, maximum
vibration absorption, reliability and rust resistance.
Removable tail light panel.
Easy to replace if
damaged and superior to welded tail light panels
which can be costly to replace. Get your trailer
back on the road quicker after minor accidents.
Contoured body.
A unique shape designed with modern vehicle aesthetics, aerodynamics and fuel efficiency in mind.
On-site power, solar and batteries.
Charge tools and run lighting anywhere with the included REDARC solar panel, battery charger, 1200W inverter with RCBO, and dual battery system.
If an earth fault occurs, RCBO (residual current circuit breaker with overcurrent protection) protects you and your tools against electrocution and fire. Ensure you can take your vehicle onto more job sites, and future proof your trailer, with this world-class electrical safety system.
Security and functionality
Single rotating latch with hardened locking rods and stainless steel striking plates offers unrivalled strength and security. The simple twist and turn latch enables one-handed operation. If damage occurs, Hidrive doors are more easily replaceable than flush mounted designs.
Flush floor system.
Never jam your fingers
against a floor lip again! Easier to unload and use
sliders and drawers.
Internal, external and under tray integrated
fixing tracks.
For easy accessory repositioning and avoiding the need to drill holes in your service body (shown with optional rubber inserts).
Internal, external and under tray integrated
fixing tracks.
For easy accessory repositioning and avoiding the need to drill holes in your service body (shown with optional rubber inserts).
Sealed tight.
The door seal channels rain away when the door is open, ensuring you and your workspace stay dry. Our positive sealing system seals against dust and water ingress when closed.
Concealed dual action adjustable hinge.
Keeps moving parts out of the weather, provides world-class security and sealing at the top, bottom and sides.
Trailer Light Lock & Go System
Includes remote central locking, door activated* internal LED lighting and 12V double cig socket. Remote central locking saves you time at every job. With its separate remote, solar and dual battery system, the trailer is a standalone workspace. (Door keys provided for manual locking.) If the Solar panels are not exposed to sunlight for extended periods, the dual battery system can be charged and electrical operation maintained with a generator or on-site power.
*Door Ajar Alarm System only available on utes/trucks.
Images are for demonstration purposes only and may differ slightly from the final product.
Case Studies
Vestas Ute and Trailer Fleet
Technical Specifications
Included Accessories
TANKS & BUNDS
| ACCESSORY | NOTES |
|---|---|
| Hand wash tank with soap dispenser, 12L | Read More |
UNDERBODY STORAGE
| ACCESSORY | NOTES |
|---|---|
| Underbody boxes, front LHS & RHS, x 2 | Read More |
INTERNAL STORAGE
| ACCESSORY | NOTES |
|---|---|
| One-Click shelving, 3 tier kit | Read More |
| Parts bin, 22 pce kit | Read More |
| Divider, mesh panel | Read More |
| One-Click vehicle drawer, 460 x 810 x 270mm, 1 tier | Read More |
| One-Click vehicle drawer, 690 x 475 x 270mm, 2 tier | Read More |
| Top pan, suits 690 x 475mm drawer | Read More |
| Top pan, suits 920 x 810mm drawer combination | Read More |
| One-Click cable hook | Read More |
FLOOR COVERINGS
| ACCESSORY | NOTES |
|---|---|
| Rubber mat, 10mm holed, profiled to body | Read More |
SECURITY LOCKING AND WARNING
| ACCESSORY | NOTES |
|---|---|
| Light Lock & Go kit, 12V, 2-door | Read More |
Weight Report
TARE WEIGHTS
| ITEM DESCRIPTION | KG/TOTAL | KG/BALLL | KG/AXLES |
|---|---|---|---|
| Kerb weight of trailer | 440.0 | 20.0 | 420.0 |
| Service body & accessories | 1035.8 | 48.6 | 987.3 |
| Totals | 1475.8 | 68.6 | 1407.3 |
OTHER SPECS
| Coupling | Trailer |
|---|---|
| Max Download 320kg | Capacity 3200kg |
| Used Download 69kg | Tare Weights 1476kg |
| Avail. Download 251kg | Avail. Payload 1724kg |
Leave no doubt.
Yes, Hidrive service body ute canopies are built with a multi-fit chassis to enable transfer to another vehicle of the same chassis size, improving resale and the lifetime value of your investment. Some have been in use for over 20 years! A Hidrive on a HiLux might be transferred to a Ranger, then a BT-50, then a Navara, Amarok or a Triton! Re-use is greener than recycling!
Your dedicated Hidrive Mobile Workspace Specialist will work closely with you to design the ideal build or fleet for your needs. Once you’re completely satisfied, they’ll assist you (or your dealership or fleet manager) through the order confirmation process to make sure everything goes smoothly. Typically, we require a 30% deposit or a purchase order from an approved customer to commence our production process.
Hidrive can licence the trailer as part of the process.
While our trailers are designed to withstand extremes, it is recommended that tailers operate within safe working limits.
We do not always have demonstration trailers at every location nationally, so please call ahead to check prior.
We do have demo utes. We can put the same full variety of service bodies (in essence) on trailers.
Please contact us to make time to view a trailer.
Yes, all 3.2 ton trailers have electric brakes.
Sizes up to 3.5 meters.
Dual-axle is offered to deliver the rigorous quality standards that we set for ourselves at Hidrive.
2.0 ton and 3.2 ton trailer chassis.
Aluminium trailers are much lighter, so they are easier to pull, better for fuel economy, have a higher load capacity, reduce braking distances, and can help to meet GCM compliance, all without compromising strength and durability. Additionally, aluminium also does not rust and looks much better if stone chips occur.
This will largely depend on compliance requirements. Feel free to speak with one of our friendly staff.
